System design document template — 9 sections, with a worked example

USE WHENYou are about to start a build and haven't decided anything on purpose yet.

A 20-minute template you fill out before writing code. Nine sections — problem, requirements, constraints, architecture, data model, API contract, failure modes, tradeoffs, open questions — each with the common mistake named and a full worked example for a Video → Transcript API.

Most bad architecture calls don't come from a wrong technical choice. They come from never actually deciding — you started building, and the first thing that worked became the design.

This template exists to make you decide on purpose, in about 15–20 minutes, instead of three weeks in when it's expensive to change. It isn't a spec document and it isn't a form to check boxes on. It's a decision log.

How to use it

1. Copy the nine sections below into a new doc for every build. One doc per build.
2. Fill every section. If you don't know the answer, write unknown — don't skip it. An honest "unknown" in Section 9 is worth more than a guess dressed up as a fact everywhere else.
3. Time-box it to 20 minutes. If a section is taking longer, you're designing prematurely — note the open question and move on.

The worked example running through this page: a Video → Transcript API. A user uploads a video, gets back an auto-generated text transcript. Every section shows how it would actually get filled out for that project, so you're never staring at a blank field.

1. Problem statement

Why this matters: if you can't state the problem in one sentence, you don't understand it well enough to design for it yet — and every section after this one inherits that fuzziness.

• What are we building, in one sentence?
• Who is it for?
• What does success look like? One measurable outcome, not a vibe.

Filled example

• Building: an API that accepts a video file and returns a text transcript within minutes.
• For: indie developers and small teams who want transcription without building Whisper infra themselves.
• Success: 95% of 10-minute videos return a transcript in under 3 minutes, for under $0.05 in compute per video.

Common mistake: writing the problem statement as a feature list ("it has upload, processing, and download") instead of an outcome. A feature list describes what you're building; it doesn't tell you why — which is exactly what you need in Section 8 when you're deciding what to cut.

2. Requirements

Why this matters: this is where scope creep actually gets killed. Not in a later "let's cut scope" meeting — here, before scope exists.

Filled example

• Must have: accept common video formats (mp4, mov); return a plain-text transcript; handle files up to 30 min / 500 MB; a basic error state when audio is unintelligible.
• Nice to have: speaker diarization ("who said what"), timestamped transcript, multi-language support.

Common mistake: putting something in must have because it'd be easy to add later, not because v1 actually needs it. Ease of implementation and necessity are different questions. This section only answers the second one.

3. Constraints and scale

Why this matters: this number decides your entire architecture. A tool for 50 users and a tool for 50,000 users are different systems, not the same system with more servers.

• Expected users / requests at launch
• Expected users / requests in 12 months
• Data volume — rows, files, GB, whatever's relevant
• Latency requirement — what response time is "fast enough"?
• Budget / infra constraints — serverless only? self-hosted? cost ceiling?
• Team constraint — solo build? what can you actually maintain?

Filled example

• Launch: ~20 videos/day.
• 12 months: ~2,000 videos/day, if it takes off.
• Data volume: avg 150 MB per video, so ~300 GB/month at the 12-month number.
• Latency: transcription can be async (the user gets notified), but upload confirmation needs to respond in under 2 seconds.
• Budget: serverless-first, under $200/month in infra until there's paying revenue.
• Team: solo — anything needing 24/7 manual babysitting is a no.

Common mistake: designing for the 12-month number on day one. Over-engineering for scale you don't have is exactly as costly as under-engineering — it just fails later and more quietly, as wasted time and unnecessary complexity instead of an outage.

4. High-level architecture

Why this matters: if you can't draw it in boxes and arrows, you don't have an architecture — you have an intention.

• Draw it: a box per component (client, API, database, third-party services, queues and workers if any), arrows for how data flows.
• One sentence per box: what does this component actually do?
• What's the single simplest version of this that could work? Start there. Add complexity only when a constraint from Section 3 forces it.

Filled example

Client (upload UI)
  → API            accepts the upload, returns a job ID
  → Queue          holds transcription jobs
  → Worker         calls the transcription model, writes the result
  → Database       stores transcript + job status
  → Client         polls, or gets a webhook when the job is done

Simplest version that could work: skip the queue entirely for launch — a single worker process pulling from a database table used as a poor man's queue. Add a real queue (SQS, Redis-backed) only once daily volume makes that polling noticeably slow, or job loss becomes a real risk.

Common mistake: designing for the tools you want to use, not the constraints in Section 3. Kubernetes and a message broker look impressive in a diagram and are mostly wasted on 20 videos a day.

5. Data model

Why this matters: every bug and every awkward feature-add downstream traces back to a data model that didn't reflect reality. This is the section worth spending the most silent, careful thinking on.

• What are the core entities, tables, or objects?
• What's the relationship between them — one-to-many, many-to-many?
• Which one field or relationship, if you get it wrong, breaks everything downstream? Flag it.

Filled example

• Entities: User, Job (one video upload = one job), Transcript (one per completed job).
• Relationships: User → many Jobs (one-to-many). Job → one Transcript once complete (one-to-one).
• The risky field: Job.status. If this isn't a strict, small enum — queued, processing, complete, failed — decided up front, you'll have inconsistent string values scattered across the codebase within a month, and every downstream feature (retries, notifications, billing) has to guess what a state actually means.

Common mistake: modeling the data around today's UI instead of the actual relationships. UIs change constantly; the relationship between a user and their jobs doesn't.

6. API / interface contract

Skip if not applicable.

Why this matters: deciding the shape of your core actions now — even loosely — saves you from an API that grew organically around whatever the frontend needed that week.

• What are the 3–5 core actions a user or client can take?
• For each: input → output, in plain language. The full spec comes later; this is just the shape.

Filled example

Common mistake: designing the API to mirror your database tables one-to-one. Your data model and your API contract are allowed to disagree. The API should reflect what a client needs to do, not how you happened to store it.

7. Failure modes

Why this matters: this is the section almost everyone skips, and skipping it is exactly why "it worked in testing" turns into a 2am page.

• What's the most likely way this breaks?
• What happens to the user when it breaks — do they see an error, lose data, or is it silent?
• What's your minimum viable fallback for the top one or two failure modes?

Filled example

• Most likely break: the transcription model times out or errors on a corrupted or unsupported file.
• What the user sees: right now, nothing — the job sits in processing forever. That's the bug to fix before launch, not after.
• Minimum fix: a timeout on the worker job (say 10 minutes) that flips status to failed with a user-facing reason, plus one automatic retry before failing permanently.

Common mistake: treating "add error handling" as a general to-do instead of naming the specific failure. "Handle errors" doesn't ship. "If the model times out after 10 minutes, mark the job failed and notify the user" does.

8. Tradeoffs

Why this matters: every real design is a set of tradeoffs, not a set of best practices. Writing them down means you chose them on purpose — and know when to revisit.

• What are you explicitly not optimizing for in v1, and why is that okay?
• What's the "cheap now, expensive later" decision you're knowingly making — and what would trigger you to revisit it?

Filled example

• Not optimizing for: multi-language transcription accuracy. English-only for v1. Okay because the target users skew English-content-first.
• Cheap now, expensive later: one shared transcription API key with no per-user rate limiting. Fine at 20 videos/day; needs per-user quotas the moment there's more than one paying customer who could accidentally — or deliberately — run up the bill. Trigger to revisit: the first paying customer. Full stop. Not "when it becomes a problem."

Common mistake: leaving the trigger to revisit vague ("when we scale") instead of a specific, checkable condition. Vague triggers never get revisited. Specific ones do.

9. Open questions

Why this matters: the goal of this template isn't to eliminate uncertainty. It's to make the uncertainty visible instead of buried.

• What don't you know yet that could change this design?
• Who or what do you need to validate this with before building?

Filled example

• Don't know yet: whether the transcription model's cost holds up at 500 MB files, or whether we need chunked processing sooner than expected.
• Need to validate: run a real cost test with a handful of large files before committing to the "$0.05/video" number in Section 1. That number is currently a guess, not a measurement.

Common mistake: treating this section as optional because the design "feels done." It's most useful exactly when you're confident — that's when unexamined assumptions do the most damage.

Quick reference

Once you know the template by heart, this is the whole thing:

Duplicate it for every new build. Don't edit your master copy.
